My SSH tunnel survived 3 minutes dead

I killed the process holding an SSH tunnel, waited three minutes, and brought it back. Same pid, same socket, same encrypted session. The forwards started carrying traffic again on the first request, and the machine on the other end never learned that anything had happened.

That should not work. SSH has no session resumption: the keys are negotiated once per connection and live only in the memory of the two processes. There is no ticket to present, nothing to reconnect with. And yet the connection came back, because "lives only in memory" turns out to be a much weaker statement than it sounds.

Why you would ever want this

Normally you would not. A background SSH tunnel that dies on reboot is a solved problem: give the machine its own key, write a unit file, let systemd restart it forever. That fixes reboots, link flaps and far-end restarts all at once, and it is what you should do.

This is about the case where you cannot. Two versions of it show up in practice, and both are becoming more common rather than less:

The credential is a physical object. The far end authenticates a hardware-backed key — a FIDO token that must be present and touched. That is the entire point of the token: no unattended machine can produce that signature. A tunnel established through it can be used forever, but never re-established without a human and a pocket.

The session was instantiated remotely, by someone who has since left. An operator connects with agent forwarding, sets up forwards on the host, and logs out. Agent forwarding deliberately leaves nothing behind: the private key never left the operator's laptop, only signatures crossed the wire. The running session is now an asset the host itself cannot reproduce.

In both cases the tunnel is not configuration, it is a capability — one that a reboot destroys and no script can recreate. Which reframes the reboot from routine maintenance into something you schedule around a person's travel plans. That was worth trying to fix.

Why it looks impossible

Ask what a live SSH connection actually consists of and you get three piles of state in two different places.

The session keys come out of a Diffie–Hellman exchange at connection setup and are never transmitted, by design. They sit in the process's heap alongside the cipher and MAC state, the packet counters, and the bookkeeping for every channel and forward. Underneath, the kernel holds the TCP socket: sequence and acknowledgement numbers, the send and receive queues, the window, the negotiated options.

And the peer holds its own mirror of all of it, which you cannot touch, cannot ask to resynchronise, and must not alarm.

There is no protocol-level way in. TLS has session tickets and QUIC has connection IDs that survive a client's address changing; SSH has neither. Nor does mosh help: it survives roaming and sleep because mosh-server keeps running on the far end, but here it is the near end that reboots, taking the session key with it. tmux reattaches a shell, not a connection.

But "the keys are in process memory" is only an obstacle if you think of memory as private. To the kernel it is a mapping you can read, and to a checkpointer it is a file.

The two halves are both capturable

The userspace half has been solvable for years: CRIU (Checkpoint/Restore In Userspace) stops a process, walks its address space, open files and mappings, and writes them to disk. Session keys are just bytes in a page; the checkpointer does not know or care what they mean.

The kernel half is the interesting one, and it exists because of CRIU. The TCP_REPAIR socket option — merged in Linux 3.5 — puts a socket into a mode where you can read out its sequence numbers and queue contents, and later write them back into a fresh socket, without any of it going on the wire. It is how container live-migration keeps connections open across a move between hosts. It is not a hack around the network stack; it is a supported door in the side of it.

Put the two together and a checkpoint looks like this:

The peer's experience of that whole sequence is one segment that went unacknowledged for a while. TCP is built for exactly that — it retransmits with exponential backoff and, by default, keeps trying for around fifteen minutes before giving up. A gap of a minute or three is well inside the envelope the protocol already tolerates.

Note the first and last steps. Before anything is frozen, the checkpointer installs a packet filter that drops traffic in both directions between the two endpoints, and it removes it only after the socket is back. That is not politeness. It is the difference between this working and not, and it is the subject of the section after next.

Doing it

My target was a background ssh holding several local forwards, started with -N, orphaned to init: no controlling terminal, stdin/stdout/stderr on /dev/null, one established TCP socket, a few listening sockets and a control socket. That shape matters, and it is a friendly one. A checkpointer's hardest problems are terminals and process trees; a forward-only SSH client has neither.

Find the process and confirm the shape:

$ ls -l /proc/$PID/fd
0 -> /dev/null
1 -> /dev/null
2 -> /dev/null
3 -> socket:[154275]      # the established connection
4 -> socket:[156124]      # a listening forward
...
$ awk '{print $7}' /proc/$PID/stat     # controlling terminal, 0 = none
0

If that last number is not zero you have a session with a terminal attached and you will need --shell-job and a good deal more patience.

The dump itself, as root:

install -d /var/lib/criu/tunnel
criu dump -t $PID -D /var/lib/criu/tunnel --tcp-established --file-locks -v4 -o dump.log

--tcp-established is what pulls in the socket. The process is gone when this returns; everything now lives in a few megabytes of image files.

The restore, which can be minutes and a reboot later:

criu restore -d -D /var/lib/criu/tunnel --tcp-established -v4 -o restore.log

Then verify through the tunnel itself — send a real request at a forwarded port and see whether the service on the far side answers. Do not verify with ssh -O check, for reasons in the gotchas below.

That is the whole mechanism, and within a single boot it worked first try once the tooling itself was fixed. Across a reboot there is one more thing, and it is the part I would have got wrong.

The reset that eats your connection

While the connection is checkpointed there is no socket. The port is not bound. If a packet arrives from the peer during that window, the kernel does what it does for any packet to a closed port: it answers with a RST, and the peer tears the connection down for good. Your images are now a perfect snapshot of a connection that no longer exists at the other end.

This is why CRIU installs those filter rules. During dump and restore it adds a mark-based pair covering both directions, which is why the package depends on a firewall library at all:

# nft list ruleset | grep -A1 'tcp sport 22'
ip saddr 203.0.113.7 ip daddr 198.51.100.4 meta mark != 0x0000c114 tcp sport 22 tcp dport 49731 drop
ip saddr 198.51.100.4 ip daddr 203.0.113.7 meta mark != 0x0000c114 tcp sport 49731 tcp dport 22 drop

Those rules live in the kernel, and a reboot takes them with it. From the moment networking comes back until your restore runs, the connection is completely unprotected — and that is precisely the window in which a machine that has been offline for a minute is most likely to receive something.

It is not theoretical. I put my own equivalent rule in place before dumping purely as a belt-and-braces measure, and its counter was non-zero within seconds. Over a three-minute gap it caught a handful of packets: the far end retransmitting a small pending segment, backing off as it went. Any one of those, arriving with no rule in place, would have ended the connection.

So a reboot needs one step a same-boot restore does not: install the drop rule yourself, before networking starts, and remove it only once the restore has succeeded.

# before the dump
iptables -I INPUT 1 -s $PEER -p tcp --sport $PEER_PORT -j DROP
# ... dump, reboot, restore ...
iptables -D INPUT   -s $PEER -p tcp --sport $PEER_PORT -j DROP

In unit terms the ordering is: rule before the network, restore after the network (the addresses your forwards bind must exist first), delete after the restore. Get that sequence wrong in either direction and you either lose the connection or restore one that can never receive anything.

Two smaller boot-time details in the same family. The source port of the old connection sits in the ephemeral range, so something else can claim it while you boot — reserve it with sysctl -w net.ipv4.ip_local_reserved_ports=$SRC_PORT before you dump. And the pid must be free; in practice it always is right after boot, and CRIU forces the matter through ns_last_pid anyway.

Three things that bit me

The distribution's own build could not checkpoint anything. Every dump died the same way:

Error (criu/parasite-syscall.c:87): si_code=4 si_pid=… si_status=11
Error (criu/parasite-syscall.c:94): … was stopped by 11 unexpectedly

Signal 11 is a segfault, and it is the parasite — the small blob CRIU injects into the target process to make it dump itself — that is dying. It had nothing to do with SSH: a plain sleep failed identically, which is the test worth running before you blame your workload.

The cause is that the parasite executes inside another process with no libc and no ordinary stack, so it must be compiled without the hardening a distro applies to everything else. This one's PKGBUILD strips _FORTIFY_SOURCE already — evidence the problem is known — but not -fstack-protector-strong or -fstack-clash-protection. Rebuilding the same version with plain flags fixed it outright:

# in build(), replacing the existing CFLAGS line
export CFLAGS="-march=armv8-a -O2 -pipe"; export CXXFLAGS="$CFLAGS"; export LDFLAGS=""

On aarch64, Arch Linux ARM, kernel 7.1.5, gcc 16.1.1, CRIU 4.2.1. Worth knowing that a system upgrade will silently put the broken build back, so pin the package. criu check --all is not a useful oracle here either — it passed with warnings both before and after, and the warnings it does emit (dirty tracking, userfaultfd, 32-bit compat) are all irrelevant to a one-shot, same-kernel dump and restore. The one that is worth heeding: with no vDSO-map API it falls back to mremap(), so do not change the kernel between dump and restore.

The multiplexing control socket does not survive. The forwards came back perfectly; ssh -O check did not, and the socket file was there but refused connections. The reason is a neat little impedance mismatch. OpenSSH binds the control socket at <path>.XXXXXXXX and then renames it into place — and rename() does not change the path the kernel recorded at bind() time. Unix sockets are reached through the filesystem inode, so connecting to the final path works fine for the original process. CRIU faithfully re-binds the name it was told, the temporary one, and materialises no filesystem entry for it; the final path still holds the old, now-dead inode. Result: a listening socket nothing can reach, and ECONNREFUSED at the path you would use.

There is no fix — a path cannot be attached to an already-bound Unix socket after the fact. It is a real limitation with a narrow blast radius: your forward set is frozen as it was at dump time, since adding one needs the control channel. Verify through the tunnel, not through -O check.

--tcp-close is not the flag you want. When a dump complains about a socket in a state other than established, the obviously-named option is a trap: it means do not preserve connections, restore them closed, which would take the master connection with it. I had picked up a couple of stray CLOSE-WAIT forwarded connections just by probing the tunnel to check it was alive. They cleared by themselves within seconds. Wait them out.

What it actually buys, and what it costs

The measured result: a three-minute outage, survived. That covers a real reboot two to three times over, which was the margin I wanted before trusting it. The far end's patience is the number you cannot look up — it depends on a ClientAlive setting you may not be able to read — so measure it on the connection you care about rather than assuming the default.

What survives: the TCP connection, the encrypted session, every forward, the pid. What does not: the control channel, and any connection that was travelling through a forward at dump time — those endpoints are on the machine that just went away.

And the honest framing. This is a way to carry an unreproducible capability across a maintenance window, not a substitute for making it reproducible. If you can put a key on the box, do that instead and never think about parasites or repair-mode sockets again. If the credential is a physical object in someone's pocket, or an agent that logged out last Tuesday, this is a genuinely good tool — and the failure mode is symmetric with doing nothing, since a botched restore leaves you exactly where a plain reboot would have.

Which is the part I find quietly satisfying. The received wisdom is that a reboot ends every session on the machine, and it is true right up until you notice that "the keys only exist in memory" describes a file you have not written yet.
